KP100 Series

The compact KP100 Series pressure controller combines a digital pressure sensor, a control valve, and PID control for closed-loop pressure regulation. It offers control accuracy of ±0.25% of full scale and an RS-485 interface. Custom configurations are available for chromatography, semiconductor processing, CVD, reactor pressure control, and other applications.

Range: ±1psi, ±15psi, 60psi, 150psi
Control Accuracy: ±0.25%F.S.
Control Range: 0.5%~100%F.S.
Response Time: <1s (0-10psi step response up to 200ms)

Request a quote

Configuration and suitability confirmed for your application.

Basic Parameters

Range	±1psi, ±15psi, 60psi, 150psi
Control Range	0.5%~100%F.S.
Control Accuracy	±0.25%F.S.
Maximum Inlet Pressure	150 psig (non-operating)
Response Time	<1s (0-10psi step response up to 200ms)

Valve Specifications

Valve Types	Normally closed
External Leak Rate	<0.020 sccm He @150 psid

Electrical Parameters

Working Voltage	DC5-24V
Power Consumption	<1.5W
Communication Protocol	MODBUS RTU (RS485)

Environmental Conditions

Operating Temperature	-10~60℃
Storage Temperature	-20~65℃
Storage Humidity	0~95%RH

Mechanical Parameters

Dimensions	27×22×35mm
Weight	50g
Compatible Gases	Noncorrosive gases including N2 and H2

Measurement conditions & notes

The KP100 electronic pressure controller provides accurate, repeatable pressure regulation with a fast response.
Pressure-reducing, back-pressure, and external pressure sensing modes are available.
RS485 is standard; settings are retained when power is removed.
Applications include gas chromatography, semiconductor processes, and environmental monitoring equipment.

Confirm fluid compatibility, materials, connections, and available configuration with our team before ordering.
